Self-Centering Mechanical Vise Ø230

Product Code - FM51900203

Self-Centering Mechanical Vise Ø230

Product Code - FM51900203



Catalogues
1. FastMill

Key data at a glance


Fixing: compatible with commercial zero points or directly on mechanical table. Operation: kinematics controlled by double screw with right and left trapezoidal thread.

Further Information


Stroke Per Joke
40 mm (1.57")
Weight
15 kg (34 lbs)
Repeatability
<2 Cents
Clamping Force
28kN

Downloads

Accessories

FastMill T-Nut

Code - FM36316028

FastMill T-Nut

Code - FM36016028

FastMill T-Nut

Code - FM36016024
