VERTICAL CLAMPING AND POSITIONING SET
Product Code - FMVCAP0016024
Key data at a glance
The Vertical Clamping and Positioning System allows for vertical clamping of medium sized components whilst ensuring a known position of the workpiece in space. The system works using our standard Fastmill modules to which vertical mounting accessories are applied. A side clamping accessory is also available for cases where clamping to the rear of the workpiece is not possible.
Further Information
| SET CONFIGURATION | N° |
| Bush Ø24-24 mm | 6 pieces |
| TCEI M16X60 mm UNI 5931-12,9 screw | 3 pieces |
| TCEI M16X40 mm UNI 5931-12,9 screw | 1 pieces |
| TCEI M16X20 mm UNI 5931-12,9 screw | 1 pieces |
| TE M16X100 mm UNI 5739-12,9 screw | 1 pieces |
| Feather key 28X16X60 DIN6885 C | 1 pieces |
| 17x30 UNI 6592-69 washer | 1 pieces |
