Key data at a glance

The mechanical zero-point clamping system for the RoboTrex 52 automation system is opened and clamped by the robot via a lever. Like the Quick•Point® zero-point clamping system, it guarantees highly accurate positioning of the clamping devises with a repeat accuracy of < 0.005 mm.

Further Information

DIMENSIONS

⌀ 157 x 37 mm (6.18" x 1.46")

CLAMPING MECHANISMS

mechanical

PACKAGING UNIT

1 Set

WEIGHT

5.2 kg (11.46 lbs)

MATERIAL

Steel

More Options:

Vice size

77 mm (3.03")

Width of compatible vice

Automatable

Yes

Automation interface included

Clamping stud size

16 mm (0.63")

Diameter of suitable clamping studs

Notice:

Scope of delivery:

Benefits RoboTrex Zero-Point Clamping System

Independence No additional utilities required within the machine tool.

Set-up time savings Fast setup and dismantling in the zero-point system.

Utilization Both automated and manual production possible.

RoboTrex Automation System

By using RoboTrex, machining hours and thus productivity can be increased. RoboTrex covers every need from single part to large-scale production. It is flexible, easy to use and offers great value for money. This makes it appealing for SME’s and for those just starting out.

Easiest operation The intuitive operation and the pre-adjusted robot do not require any special knowledge. Training is kept to a minimum.

Fastest set-up time Thanks to offline preparation of the trolleys, the system is set up within a few moments without any machine downtime.

Highest flexibility Both the offline trolley preparation and the diversity of machinable parts guarantee maximum flexibility.
