Quick•Point® 96, Round Plate ø 246 x 27 mm, without mounting bores, for individual centre hole
Product Code - 45843
Key data at a glance
The special arrangement of the clamping mechanism inside the plate allows not only the insertion of mounting holes and keyways, but also an individual center hole up to Ø 80 mm, which offers a possibility for rotary joints. This zero-point plate is clamped via 2 opposite actuation screws.
Further Information
More Options:
Torque
30 Nm
Maximum allowed torque
Vice size
125 mm
Width of compatible vice
Clamping stud size
20 mm (0.79")
Diameter of suitable clamping studs
Notice:
-
Scope of delivery:
Benefits Quick•Point® Single Plates
Quick•Point® Zero-Point Clamping System
The Quick•Point® Zero-Point Clamping System is characterized by a particularly wide range of variations and provides a solution for any machine tool. Whether round, rectangular or square in shape, for single or multiple clamping, it can be universally used in vertical and horizontal machining centers, on 3- and 5-axis tables and 4th axis rotary or trunnion systems.
